Industrial Multimedia Water Filtration Plant

The purpose of UltraTec multi-media filters is to remove suspended materials larger than 10 microns. The desired effluent water quality and the feed water analysis are taken into consideration while designing the media filters. Media filters can be supplied alone or as a component of a whole water treatment system. The media filter’s control system may be isolated from the rest of the water system or specifically designed for the filter. Filtration systems are made especially for your application out of materials such as stainless steel, lined carbon steel, fibreglass, or PVC. Additionally, every filter may come with the best bundle—a feature set that offers even more value.

What This System Does

Multimedia filtration systems remove suspended solids, turbidity, and larger particles from feedwater before further treatment. These systems are used as essential pretreatment in RO plants and industrial water systems where untreated water contains sediments and impurities.

Ultratec designs each multimedia filtration plant based on feedwater analysis and required flow rate. The system configuration, media selection, and vessel type are engineered for your site conditions to ensure reliable long-term filtration performance.

Powerful and Efficient Water Filtration

MODEL	DIAMETER in INCHES [MM]	FLOW RANGE in GPM [LPM]
MMF12	12 [305]	2-9 [8-34]
MMF18	18 [457]	4-21 [15-79]
MMF24	24 [610]	6-38 [23-144]
MMF30	30 [762]	10-59 [38-223]
MMF36	36 [914]	14-85 [53-322]
MMF42	42 [1067]	19-115 [72-435]
MMF48	48 [1219]	25-151 [95-572]
MMF54	54 [1372]	32-191 [121-723]
MMF60	60 [1524]	39-236 [148-893]
MMF66	66 [1676]	48-285 [182-1079]
MMF72	72 [1829]	57-339 [216-1283]
MMF78	78 [1981]	66-398 [250-1507]
MMF84	84 [2134]	77-462 [297-1749]
MMF90	90 [2286]	88-530 [333-2006]
MMF96	96 [2438]	101-603 [382-2283]
MMF102	102 [2591]	113-681 [428-2578]
MMF108	108 [2743]	127-763 [481-2888]
MMF114	114 [2896]	142-851 [538-3221]
MMF120	120 [3048]	157-942 [594-3566]

Notes: Vessels up to 48” (1219 mm) in diameter are available in fiberglass. All vessels are available in carbon steel lined with Plasite 7159 and 316L stainless steel. Piping on fiberglass and carbon steel vessels is available in PVC, CPVC, and 316L stainless steel. Piping on 316L stainless steel vessels is available in 316L stainless steel.

OVERVIEW

Available individually or as part of a total water treatment solution
Full scope of materials of construction for any application – fiberglass, PVC, CPVC, lined carbon steel and stainless steel.
Flexibility in controls: independent or part of a central control system.

Efficient component layout allows for ease of maintenance and calibration.
Customizable to customer specifications for valves, instruments and other mechanical components.
Optional complete validation package with IQ/OQ protocol execution.
Supported by Toll Free 0800-ULTRA & Hot Line: +971-50-849-5110 24-hour customer service
Backed by warranty

Equipment Details

PLC based control
Instrumented for operation and for maintenance
Premium valves and instrumentation
Galvanized rigid steel conduit
Stainless steel airlines
Stainless steel hardware

Models

Features

Standard Features:

Complete face piping configuration
Reduces number of terminal points
Reduces site piping cost and time
Generous freeboard
Reduces resin loss during backwash
Specialized distributor and underdrain design
Ensures proper flow distribution
Ensures proper flow distribution
Eliminates resin loss
No downstream resin trap or filter required
Pneumatic panel housing all pneumatic components facilitates maintenance and calibration

Available Options:

Fully automatic PLC-based control system
Pneumatic or motorized valve operation
Stainless steel or lined carbon steel vessel construction
UV sterilization or post-treatment integration
Differential pressure monitoring system
Remote monitoring and control integration
Custom piping materials including PVC, CPVC, or stainless steel
Containerized or modular system design
Pre-treatment dosing systems integration

Applications

Suitable for industrial, commercial, and infrastructure projects across UAE and Gulf region where pre-filtration is required.

Reverse osmosis system pretreatment
Industrial process water treatment plants
Cooling tower and boiler feedwater systems
Food and beverage production facilities
Oil and gas field water treatment
Municipal and infrastructure water systems
Irrigation and agricultural water supply
Commercial building water filtration

Why Ultratec

Ultratec is an ISO 9001:2015 certified water treatment company based in UAE with experience across industrial and infrastructure projects. Every filtration system is engineered based on feedwater quality, site conditions, and required performance. Components are sourced from certified global manufacturers to ensure durability and consistent operation. Our UAE-based technical team handles supply, installation, commissioning, and after-sales support.

Frequently Asked Questions

Can this multimedia filter be customized for our water source?

Yes. Each system is configured based on feedwater analysis and required flow rate. Contact our team to start with a site assessment.

Do you supply and install across UAE?

Yes. Ultratec provides full supply, installation, and commissioning across UAE and Gulf region.

Is maintenance and support available after installation?

Yes. We provide maintenance services, spare parts, and technical support. Contact our team for service plans.

Get In Touch

Contact our team in Dubai to discuss your water treatment requirement and receive a solution configured for your site.

Chat on WhatsApp

System Components

Certified Parts. Proven Performance.

We use certified components sourced from trusted global manufacturers to ensure system durability, operational stability, and regulatory compliance. From membranes and pumps to control panels and filtration media, every part is selected to support long-term performance and ease of maintenance.
